Recommended twisted pair cables
10 · G&D Dynamic-UserCenter 32
Recommended twisted pair cables
The expansion Dynamic-UserCenter 32 is installed as component of a DVICenter sys-
tem. All signals within the system are transmitted over twisted pair cables (category
5e or better).
The data transmission is reliable over a distance of at least 80 metres using a regular
standard twisted pair cable (category 5e or better).
The distance that can actually be bridged depends on the quality of the applied
cable. High-quality S-STP cables with an AWG22 wire gauge coding can bridge a
distance of up to 140 metres.
Patch cables with an AWG26 wire gauge coding can only bridge a maximum of 80
metres.
In order to ensure a reliable operation even in environments with interferences,
installation cables with at least AWG24 coding have to be used for lengths over 80
metres:
The following cables achieved the best results during test operation:
NOTE: It is permitted to connect several segments of a cable connection with patch
panels and connection ports. It is, however, not permitted to connect active com-
ponents such as network switches, hubs or repeaters are not permitted.
Wire gauge Cable type Category Recommendation
AWG22 Installation 5e, 6 or 7 Up to 140 m
AWG24 Installation 5e, 6 or 7 Up to 120 m
AWG26/27 Patch cable 5e, 6 or 7 Up to 80 m
NOTE: The lengths listed in the table above are the sum of all segments between
the devices.
Up to 80 meters: Dätwyler uninet® 7702 flex
 Patch cable
Up to 100 meters: Dätwyler uninet® 5502 AWG24 S-STP
 Installationcable with sockets
Up to 140 meters: Kerpen MegaLine® G12-150 S/F AWG22
 Installation cable with sockets
Dätwyler uninet® 7702 AWG 22
 Installation cables with sockets
