Status displays
14 · G&D Dynamic-UserCenter 32
Changing the view modes of »Dynamic Port« LEDs
In the device’s default settings, the LEDs of the Dynamic Ports show the interface’s
status.
To facilitate the installation, you can switch the LEDs of the Dynamic Ports into Port
mode. In Port mode, the Dynamic Ports to connect the matrix switches or the user
modules are highlighted by green or yellow LEDs.
How to enable the Port mode of Dynamic Ports:
1. In the tree view, click UserCenter .
2. Right-click the device, and select Dynamic Port LEDs > Show port type from the menu.
3. Choose System to show the port modes of all ports, or choose the port group to
which you want to limit the highlighting LEDs to.
The LEDs of the Dynamic Ports highlight the current port mode (see table above).
Interface LED Status Meaning
Dynamic Port Green On  Status mode:
Connection to matrix switch or to target module estab-
lished.
 Port mode:
The port is configured to connect a target module (CPU
port).
Off A connection to the matrix switch or to the target mod-
ule could not be established.
Ident. Ident. On LED to identify the device in the web application is active.
Blinking Port type is shown at Dynamic Ports.
Power Red. On The redundant power pack is turned on and supplies the
required voltage.
Off The redundant power pack is turned off or the connec-
tion to the mains could not be established.
Main On The main power pack is turned on and supplies the
required voltage.
Off The main power pack is turned off or the connection to
the mains could not be established.
NOTE: If the port modes are active, the Identification LEDs on the device’s front
and back side are blinking.
