22. Reconnect the 6 cord wires to the PCBA:
Red to E1 Green to the right side E2 Black to E3
Yellow to E4 White to the left side of E2 Blue to E5
23. Replace the 2 top panel screws and the 2 bottom panel screws to reassemble the unit.
24. Use the 2 mounting screws to secure the subset to the mounting bracket.
Models 9201A and 9205A
Removal of Old Cord
1. Remove the unit from the wall or the mounting surface.
2. Remove the 4 back panel screws.
3. Remove the 6 cord wires from the PCBA:
Red from E1 Green from the right side E2 Black from E3
Yellow from E4 White from the left side of E2 Blue from E5
4. When replacing an existing PVC cord, use the Heyco ® bushing tool or a needle nose pliers to squeeze
the notch on the outer side of the strain relief bushing and pull out the bushing. Pull the cord through
the hole and remove the cord.
5. When replacing a thermoplastic elastomer cord, remove the handset cord fastener clip located on the
back side of the front panel. The fastener clip secures the bushing and the cord to the front panel.
6. At the handset end, unscrew the transmitter cap, lift out the transmitter and disconnect the black and
white wires.
7. Unscrew the receiver cap and lift out the receiver. Disconnect the red and green wires from the
receiver.
8. Using the Allen wrench, loosen the 2 Allen nuts securing the pressbar. Lift out the plastic pressbar, the
metal casing and the 2 pieces of copper.
9. Lift out the rectangular plastic cup and disconnect the yellow and blue wires. Pull the old cord out of
the handset.
Installation of New Cord
10. Feed the red and green wires through the transmitter end of the handset, through the center of the
handset to the receiver end. Secure the red and green wires to the receiver.
11. Place the receiver into its location. Tighten the receiver cap.
12. Feed the yellow and blue wires through the handset pressbar area.
13. Secure the yellow and blue wires to the terminals in the plastic cup. Place the plastic cup in the
handset.
14. Refer to Figure 1. Place the copper piece with the rubber center in first, with the solid rubber side
outward.
15. Place the other copper piece so that the bend faces outward.
16. Place the plastic piece so that that GAI-Tronics logo side is facing outward. Place the metal bracket on
top and tighten the Allen screws.
17. Attach the black and white wires to the transmitter.
18. Place the transmitter into its location, making sure that the cord guide snaps firmly onto the cord to
secure it. Tighten the transmitter cap.
19. Feed the other end of the cord through the panel from the front of the unit.
