Model 69440-001 Master Control Unit PCBA
Page: 8 of 8
\\s_eng\gtcproddocs\standard ioms - current release\42004 instr. manuals\42004-676l2b.doc
04/05
Specifications
Electrical
Power ......................................................................................................3 A maximum @ +5 V dc
±5%
20 mA maximum @ +12 V dc
±10%
20 mA maximum @ -12 V dc
±10%
Battery ......................................................................................................................................... 3 volts
0.03 mA standard load
Lithium Coin Cell/48 mAh capacity
Environmental
Temperature range (operating/storage)................................................+32 ºF to +120 ºF (0 ºC to +49 ºC)
Humidity: .......................................................................... 10% - 85% non-condensing relative humidity
Mechanical
Unit dimensions .............................................. 10.3 H
× 1.63 W × 9.07 D inches (262 × 41.3 × 231 mm)
Unit weight .................................................................................................................. 1.55 lbs. nominal
Approval
CE Mark ....................................................... Complies with Low Voltage Directive 73/23/EEC, and the
EMC Directive 89/336/EEC amended by the Directive 93/68/EEC.
Replacement Parts
GTC Model No.
Manufacturer /Model No.
Description
40005-005
Panasonic - BR1225
Rayovac – BR1225
Battery, 3V Lithium Coin Cell
