Pub. 42004-676L2B

Model 69440-001 Master Control Unit PCBA

Page: 4 of 8

\\s_eng\gtcproddocs\standard ioms - current release\42004 instr. manuals\42004-676l2b.doc
04/05

Operation

After installation and power-up, the MCU starts automatically. It requires no direct user intervention
during normal operations.

In general, the MCU maintains data communication with all other cards in the card rack and with
SmartSeries devices located throughout the system. Its software configuration file defines the actual
operation of the MCU. Your system manual provides specific information how the MCU controls the
operation of your specific system.

The connections on the MCU are for use by factory-trained personnel only, unless explicitly stated
otherwise in your system manual. Although these connections are the same as those found on a PC, and
the MCU functions similarly to a PC, it is to be used strictly for operating the SmartSeries system and
should not be used for performing other functions. Failure to follow this advice could result in the failure
of your system.

Installation and Maintenance

Direct questions about installation and updating the system software configuration of this product to the
GAI-Tronics Field Service Department at 800-492-1212 inside the USA or 610-777-1374 outside the
USA.

WARNING

Disconnect power to the card rack before performing any maintenance.

Installation Instructions

Refer to Figure 1 for component location and installation details.

1. Verify that power is disconnected to the card rack prior to installation.

2. Find the slot located on the farthest left side of the card rack.

3. Align the MCU into the upper and lower tracks in the card rack.

4. Connect the Ethernet cable supplied within the card rack.

5. Slide the MCU toward the rear of the card rack until it comes in contact with the connectors on the

backplane.

6. Firmly press on the front bezel until the MCU is seated in the back-plane connectors, and tighten the

two screws located on the front bezel to secure it to the card rack.
