Scenario 2 – FSR HD-HAUD-SP-RX User Manual
Page 10
10
Scenario 2
The DVD Player can be controlled from the Receiver’s location with the DVD
Player Remote. The IR emitter is connected to the IR OUT on the Transmitter and
the IR receiver is connected to the IR IN on the Receiver.
The HD-H-SP-Tx Transmitter is shown in the illustrations throughout this manual. Please
note that any of the FSR 100m HD transmitters may be used with the HD-HAUD-SP-Rx
Receiver.
HD-HAUD-SP-Rx
HD-H-SP-Tx
HDBaseT
BLUE-RAY
DVD
TV
IR RECEIVER
CABLE
IR EMITTER
CABLE
DVD REMOTE
NORMAL
UPDATE
HDMI IN
Tx Rx
IR OUT
IR IN
+
-
DC 12V
-
+
RJ
+
-
DC 12V
-
+
Tx Rx
IR OUT
IR IN
LOCAL OUT
R
L
AUDIO AMP
