1 2 3
3 2 1
A
B
D
A
B
D
C C
244 BERGEN BLVD.
W. PATERSON, NJ 07424
TEL (973) 785-4347
FAX (973) 785-3318
TITLE:
DRAWN BY:
DWG#:
DATE: REV:
SCALE:
JRE 11/03/08 02
1:3 C-1042A
SMART FIT SF-IPSP
ASSEMBLY INSTRUCTIONS
PAGE: 3 3 OF
FSR
inc. STEP 3 - POKE-THRU
(SHOWN REDUCED IN SCALE)
FSR MODEL# SF-PK1
TILE FLANGE FSR MODEL# SF-(X)T-CV
OR CARPET FLANGE (SHOWN BELOW)
FSR MODEL# SF-(X)C-CV
AC DIVIDER (SUPPLIED
WITH SF-IPSP)
FSR MODEL# SF-IPSP
(ASSEMBLED WITH COMPONENTS)
COVER (SUPPLIED WITH
SF-(X)T-CV AND SF-(X)C-CV
(4) #6-32 x .625 LONG SCREW (SUPPLIED
WITH SF-(X)T-CV AND SF-(X)C-CV)
