Chapter 2 Installation Instructions
10
This motherboard includes connectors for FDD devices, IDE HDD devices,
SATA devices, USB devices, IR module, CPU fan, system fan, and others.
FLOPPY
This motherboard includes a standard FLOPPY interface, supporting 360 K, 720 K,
1.2 M, 1.44 M, and 2.88 M FDDs.
IDE Connectors: PIDE & SIDE
These connectors support the provided UltraDMA133/100/66 IDE hard disk rib-
bon cable and you can configure as a disk array through RAID controller. Refer
to RAID manual (in CD) for details on how to set up RAID configurations.
Connect the cable’s blue connector to the primary (recommended) or second-
ary IDE connector, then connect the gray connector to the slave device (hard
disk drive) and the black connector to the master device.
Other Connectors
Attention:
If you install two IDE device, you must configure the second drive
as a slave device.
Front Panel Connector: FP1
This motherboard includes one connector for
connecting the front panel switch and LED
indicator.
NC
HDD-LED
RESET-SW
PW R-LED
PWR-SW
9 10
1 2
FP
FP1
!
+
-
+
-
Hard Disk LED Connector (HDD-LED)
The connector connects to the case’s IDE indicator LED indicating the activity
status of hard disks.
Reset Switch (RESET-SW)
Attach the connector to the Reset switch on the front panel of the case; the
system will restart when the switch is pressed.
