REV 2 - 1502191555 L-C2-387 21
Fig. 21-1 Control knobs
FANS LIGHTS
VENT HOOD FANS
To operate the fans, simply turn the fan knob located on
the front right of the vent hood to your desired setting. The
fan knob is symbolized with a fan logo etched beside it.
See Fig. 21-1.
Turn the knob to OFF position to turn the fans off.
Always turn the fans on before cooking to establish an air
fl ow. Allow the fans to operate for few minutes after you turn
the grill off, to clear the air out and keep the area smoke free.
Note: The vent hood is equipped with an internal thermal
switch. When the surrounding area reaches
temperature, the thermal switch will automatically
turn on the vent hood fans. When the vent hood is
operating on the LO setting, it will automatically
switch to the HI setting to maintain a safe operating
temperature. This feature is for convenience and
prevents damage to the vent hood.
GRILL TOP LIGHTING
The halogen lights are controlled by turning the light knob
located on the front right side of the vent hood to your desired
setting. The light knob is symbolized with a light bulb logo
etched beside it. See Fig. 21-1.
Turn the knob to OFF position to turn the lights off.
Clean the vent hood on a regular basis to ensure optimal
performance. See the SERVICING AND CLEANING
section for details.
OPERATION
