Fire Magic 36-VH Vent Hood - Manual (Page 10)

REV 2 - 1502191555 L-C2-387 10
R O O F
SOFFIT *
(To enclose transition and area above hood. Some installs may not
require a soffi t, as countertop height & roof height may vary. )
S
P
A
C
E
R
* †
R
E
A
R
W
A
L
L
HOOD
Transition
(rear of vent hood
must align with
rear of grill oven)
Spacer * †
Soffi t *
X
Y
Z
Custom Spacer Detail * †
Model A B C
36-VH 18"
distance from
rear wall to rear
of grill oven
36"
42-VH 18"
distance from
rear wall to rear
of grill oven
42"
48-VH 18"
distance from
rear wall to rear
of grill oven
48"
60-VH 18"
distance from
rear wall to rear
of grill oven
60"
30-33"
Note: Drawings are not to scale.
* Spacer/soffi t may be constructed of wood, metal framing, etc. Upon install completion; the exposed sides of the spacer/
soffi t may be fi nished with drywall or other appropriate materials. Dimensions provided here include any fi nishing substrate.
† The front of the spacer (that is exposed to the rear of the vent hood); must include a solid wall to allow for the vent hood
to be properly secured into it. The soffi t must allow permanent interior access (i.e. access panel/door).
INSTALLATION REQUIREMENTS - CUSTOM SPACER & SOFFIT
(bracket)
7.125" (to bracket center line)
• THIS VENT HOOD IS FOR OUTDOOR, WALL MOUNT INSTALLATION ONLY.
• Installation must be done by a qualifi ed professional service technician.
• Below is a diagram of a generic installation.
• Please review and understand this section prior to proceeding with installation.
Custom Soffi t Detail *
Model X Y Z
36-VH
distance from
top of vent
hood to roof
B dimension
of spacer
+ 12"
36"
42-VH
distance from
top of vent
hood to roof
B dimension
of spacer
+ 12"
42"
48-VH
distance from
top of vent
hood to roof
B dimension
of spacer
+ 12"
48"
60-VH
distance from
top of vent
hood to roof
B dimension
of spacer
+ 12"
60"
A
B
C
VENT PIPING
Install 10" round galvanized (single wall) vent piping as required.
Installation will depend on roof construction.
REFER TO INSTALLATION SECTION FOR COMPLETE DETAILS REGARDING ALL INFORMATION FOUND ON THIS PAGE.
When constructing a custom spacer and soffi t, reference the information below for an overall orientation.
GAS
GRILL
