If the vehicle requires more than one ignition as per the Web site

information follow the same test procedure and solder the thick

PINK/WHITE (F) relay wire to it and be sure to wrap the

connection with electrical tape. If your vehicle requires more

than two ignitions, contact BOA Technical Support.

step 3

Accessory and Starter wires

The starter and accessory wires will be located in the same harness

as the ignition and constant power.

To find the accessory wire leave the LED tester black lead

connected to the metal ground, take the red lead and probe the

wire suspected to be the accessory. With the key off, your LED

tester should not illuminate. Turn the key to the on position and

the LED tester should be illuminated. Now turn the key to the

crank position. If you have the correct accessory wire the voltage

will disappear while the starter is cranking and return once the key

returns to the on position. If the wire tests correctly, strip the insu-

lation off a small portion and solder the thick ORANGE (C) relay

wire to it and wrap it with electrical tape. If your vehicle requires

more than one accessory contact BOA Technical Support.
