Denon AVR-4308CI - Manual (Page 88)

Setting
Status Speaker terminal
ZONE2 ZONE3 SURROUND A
SURROUND
BACK
SURROUND B/
ASSIGN
ASSIGN-2
ZONE2
ON
ON SLA/SRA – SLB/SRB Z2 L/R
OFF SLA/SRA – SLB/SRB Z2 L/R
OFF
ON SLA/SRA SBL/SBR SLB/SRB –
OFF SLA/SRA SBL/SBR SLB/SRB –
ZONE3
ON
ON SLA/SRA – SLB/SRB Z3 L/R
OFF SLA/SRA SBL/SBR SLB/SRB –
OFF
ON SLA/SRA – SLB/SRB Z3 L/R
OFF SLA/SRA SBL/SBR SLB/SRB –
ZONE
(MONO)
ON
ON SLA/SRA – SLB/SRB Z2/Z3
OFF SLA/SRA – SLB/SRB Z2/Z3
OFF
ON SLA/SRA – SLB/SRB Z2/Z3
OFF SLA/SRA SBL/SBR SLB/SRB –
Bi-Wiring &
ZONE2
ON
ON SLA/SRA – FL/FR Z2 L/R
OFF SLA/SRA – FL/FR Z2 L/R
OFF
ON SLA/SRA SBL/SBR FL/FR –
OFF SLA/SRA SBL/SBR FL/FR –
Bi-Wiring &
ZONE3
ON
ON SLA/SRA – FL/FR Z3 L/R
OFF SLA/SRA SBL/SBR FL/FR –
OFF
ON SLA/SRA – FL/FR Z3 L/R
OFF SLA/SRA SBL/SBR FL/FR –
Bi-Wiring &
ZONE(MONO)
ON
ON SLA/SRA – FL/FR Z2/Z3
OFF SLA/SRA – FL/FR Z2/Z3
OFF
ON SLA/SRA – FL/FR Z2/Z3
OFF SLA/SRA SBL/SBR FL/FR –
ZONE2/
ZONE3
ON
ON – – Z3 L/R Z2 L/R
OFF SLA/SRA – SLB/SRB Z2 L/R
OFF
ON – – Z3 L/R Z2 L/R
OFF SLA/SRA SBL/SBR SLB/SRB –
ZONE2/3
(MONO)
ON
ON – – Z3(MONO) Z2(MONO)
OFF SLA/SRA – SLB/SRB Z2(MONO)
OFF
ON – – Z3(MONO) –
OFF SLA/SRA SBL/SBR SLB/SRB –
Multi-Zone Power On/Off
Setting
Status Speaker terminal
Surround mode SURROUND A SURROUND BACK
SURROUND B/
ASSIGN
ASSIGN-2
2ch Bi-Wiring
STEREO/DIRECT – – FL/FR FL/FR
Other SLA/SRA SBL/SBR – –
2ch Bi-Amp
STEREO/DIRECT – – FL/FR FL/FR
Other SLA/SRA SBL/SBR – –
STEREO or DIRECT (2ch) Mode
Relationship Between Amp Assign Setting and
Speaker Output
