Denon AVR-4308CI - Manual (Page 35)

g Manual EQ
Adjust tonal quality for each speaker using graphic
equalizer.
Adjust CH
Select speaker adjustment method.
[Selectable items] Each L/R All
Manual EQ
Select the speaker and frequency band and adjust the level.
[Selectable items] 63 125 250 500 1k 2k 4k
8k 16k
Curve Copy
Copy “Audyssey Flat” curve from Room EQ.
[Selectable items] Yes No
“Curve Copy” is displayed after the auto setup procedure has been
performed.
Default
Resets the settings to the default values.
Network Setup
Make network settings.
F Menu tree F
Manual Setup
Network Setup
Network Setup
Other
Network Information
a Network Setup
Make settings for wired or wireless LAN.
Wired LAN
Make settings for wired LAN.
If a Ethernet cable is connected
To acquire the IP address automatically
using the DHCP function
To enter the IP address manually
Turn on the AVR-4308CI’s power.
At the GUI menu “Manual Setup” – “Network
Setup” – “Detail” setting, set “DHCP” to “OFF”
and enter the IP address, subnet mask, default
gateway, primary DNS and secondary DNS.
To not pass through the proxy server To connect via proxy server
At the GUI menu “Manual Setup” – “Network
Setup” – “Proxy” setting, set “Proxy” to “ON”
and enter the address or domain name and
port numbers.
This setting is required when the network
is established via proxy servers.
Recheck the connections and settings if you cannot connect to the Internet (vpage 20).
The mode automatically switches to “Wired”.
This completes the setting.
[Variable range] –20dB ~ 0dB ~ +6dB
32
Get
ting Star
ted
Connections
Set
up
Pla
ybac
k
Remot
e Contr
ol
Multi-Zone
Inf
or
mation
Tr
oubleshooting
NOTE Knowledge about networks is required to make the IP address and proxy settings. For details, consult a network administrator.
