68
Get
ting Star
ted
Connections
Set
up
Pla
ybac
k
Multi-Zone
Inf
or
mation
Tr
oubleshooting
Remot
e Contr
ol
Device operated
SAT TU
(XM)
NET / USB iPod
Zone selection M Z2 Z3 Z4 M Z2 Z3 Z4 M Z2 Z3 Z4
ZONE SELECT Zone operation mode selection Zone operation mode selection Zone operation mode selection
ZONE OFF Power turned off (b1) Power turned off (b1) Power turned off (b1)
ZONE ON Power turned on (b1) Power turned on (b1) Power turned on (b1)
SOURCE SELECT Input source selection – Input source selection (b2) Input source selection –
CHANNEL + / – Preset channel selection – Preset channel selection –
SHIFT
Preset channel memory
block selection
–
Preset channel memory block
selection
–
VOLUME + / – Adjustment of volume (b1) – Adjustment of volume (b1) – Adjustment of volume (b1) –
MUTE Muting (b1) – Muting (b1) – Muting (b1) –
MENU Selected zone menu – Selected zone menu – Selected zone menu –
u i o p Category search – File operations – File operations –
ENTER – File operations – File operations –
SEARCH –
Page forward screen /
Character search
–
Page forward screen /
Browse/Remote mode
switching (press and hold)
–
RETURN – File operations – –
8 9 ,
TUNING d f
Channel selection – Track search Track search –
2 – Stop Stop –
1/3 – Play/pause Play/pause –
REPEAT – 1-track/All-track repeat play (USB) 1-track/All-track repeat play –
RANDOM – 1-track random play (USB) 1-track/album shuffle play –
USB b 3 – b 3 b 3 –
ALL MUSIC *
(Music server only)
b 4 – b 4 b 4 –
FAVORITES * b 5 – b 5 b 5 –
b 1: Affects the currently selected zone.
b 2: In ZONE4, it is not possible to select “XM”, “HD Radio”, or sources with no digital input signals (“TUNER”, “PHONO”, “iPod”, etc.).
Network audio signals (Internet radio, music server, USB) can be played as long as they are not copyright-protected.
b 3: The input source switches to “NET/USB” and the files on the USB memory device are played.
b 4: The input source switches to “NET/USB” and the files in “All Music” on the music server are played.
b 5: The input source switches to “NET/USB” and the files in “Favorites” are played.
*: Whether “All Music” or “Favorites” is selected depends on the “Direct Play” setting (vpage 40).
Switching Zones
Use this procedure to select the zone to be operated by
the sub remote control unit.
1 Press [ZONE SELECT] .
The currently selected multi-zone indicator lights.
2 While the multi-zone indicator is light, press [ZONE
SELECT] to select the zone to be operated.
The currently selected multi-zone indicator lights.
Setting the Zone for Which the Sub
Remote Control Unit is Used (ZONE
SELECT LOCK Mode)
We recommend always using the sub remote control unit
for the same room. When this is done, the unit can be
set so that the zone does not switch when buttons are
operated.
1
Use the tip of a pen to press [ADVANCED SETUP] .
All the multi-zone indicators light.
2 Select the multi-zone to be set.
The selected multi-zone indicator lights.
q To set to “MAIN ZONE” : Press [REPEAT].
w To set to “ZONE2” : Press [RANDOM].
e To set to “ZONE3” : Press [USB].
r To set to “ZONE4” : Press [ALL MUSIC/FAVORITES].
3 Use the tip of a pen to press [ADVANCED SETUP] .
The multi-zone indicator turns off.
To Cancel
1 Use the tip of a pen to press [ADVANCED SETUP] .
The currently selected multi-zone indicator lights.
2
Press [ZONE SELECT].
All the multi-zone indicators light.
3
Use the tip of a pen to press [ADVANCED SETUP] .
The multi-zone indicator turns off.
