Front Rear
All One OFF
ON OFF
Assign None
NET/USB
iPod dock
Assign Control Dock for iPod to this source.
CD DVD HDP TV/CBL SAT VCR
DVR V.AUX
[Input source]
[Selectable items]
A0 Playback Mode
Make settings for “NET/USB” playback.
[Input source]
USB Select
Select USB port to use.
[Selectable items]
[Selectable items]
[Selectable items]
Repeat
Make settings for repeat mode.
Random
Make random mode settings.
NOTE
This cannot be set for input sources for which “iPod dock” is
assigned.
Favorites All Music
Direct Play
Set the folder to be played using the DIRECT PLAY button on the sub
remote control unit.
[Selectable items]
Input
source
DVD HDP TV/CBL SAT VCR DVR V.AUX
Default
setting Component
1
Component
2
Component
3
None None None None
40
Get
ting Star
ted
Connections
Set
up
Pla
ybac
k
Remot
e Contr
ol
Multi-Zone
Inf
or
mation
Tr
oubleshooting
Match the port to be used and the setting.
Coaxial1 ~ 3 Optical1 ~ 4
DENON LINK z None
CD DVD HDP TV/CBL SAT
VCR DVR V.AUX
• With HDMI, the video and audio signals are transferred simultaneously.
To play the video signal assigned at “HDMI” combined with the
audio signal assigned at “Digital”, select “Digital” at GUI menu “Input
Mode” (vpage 39).
• When the AVR-4308CI and monitor are connected with an HDMI
cable, if the monitor is not compatible with HDMI audio signal
playback, only the video signals are output to the monitor.
• The audio signals input from the analog, digital and EXT. IN connectors
are not output to the monitor.
NOTE
This cannot be set for input sources for which “iPod dock” is
assigned.
Digital
Select digital input connector to assign to this source.
[Input source]
[Selectable items]
z : When a DENON DVD player and the DENON LINK have been
connected, be sure to make a setting to “DENON LINK”.
NOTE
• This cannot be set for input sources for which “iPod dock” is
assigned.
• When “DENON LINK” is assigned at the GUI menu “Assign” setting,
the PCM signals, network audio signals (Internet radio, music server
and USB), XM signals and HD Radio signals input from the digital
input connectors cannot be output from the ZONE2 and ZONE3
audio output connectors and the analog REC OUT connectors.
Component
Select component video input to assign to this source.
1 2 3 None
DVD HDP TV/CBL SAT VCR
DVR V.AUX
[Input source]
[Selectable items]
Input
source
CD DVD HDP TV/CBL SAT VCR DVR V.AUX
Default
setting Coaxial
3
Coaxial
1
None
Coaxial
2
Optical
1
Optical
3
Optical
2
Optical
4
1 2 3 4 None
DVD HDP TV/CBL SAT VCR
DVR V.AUX
l Assign
Assign input sources to input connectors.
HDMI
Select HDMI connector to assign to this source.
[Input source]
[Selectable items]
Input
source
DVD HDP TV/CBL SAT VCR DVR V.AUX
Default
setting
HDMI1 HDMI2 HDMI3 None None HDMI4 None
• With the default settings, the Control Dock for iPod can be used
connected to the VCR (iPod) connector.
• Even if “iPod dock” is set to “Assign”, if the set is not connected to
a Control dock for iPod, the input source can be used as the normal
input source.
