Input signal Display
Dolby
Digital
Source
DOLBY DIGITAL
(other than 2ch) /
DOLBY DIGITAL
EX
DOLBY DIGITAL
DOLBY DIGITAL EX
DOLBY DIGITAL+PLgx CINEMA
DOLBY DIGITAL+PLgx MUSIC
DOLBY DIGITAL
Plus DOLBY DIGITAL +
DOLBY TrueHD DOLBY TrueHD
DTS
Surround
Source
DTS (5.1ch) /
DTS-ES Discrete
6.1 /
DTS-ES Matrix
6.1 /
DTS 96/24
DTS SURROUND
DTS+PLgx CINEMA
DTS+PLgx MUSIC
DTS+NEO:6
DTS ES MTRX6.1 (z1)
DTS ES DSCRT6.1 (z2)
DTS 96/24 (z3)
DTS-HD High
Resolution Audio
DTS-HD HI RES
DTS-HD Master
Audio
DTS-HD MSTR
DVD-
Audio,
SACD
PCM (multi ch) /
DSD (multi ch)
MULTI CH IN
MULTI IN+PLgx CINEMA
MULTI IN+PLgx MUSIC
MULTI CH IN 7.1
Select the “Cinema”, “Music”, “Game” and “Pro Logic” modes at GUI
menu “Parameter” – “Audio” – “Surround Parameters” – “Mode”
(vpage 42).
z 1 : This is displayed when the input signal is “DTS-ES Matrix 6.1”
and the AVR-4308CI’s “AFDM” setting is set to “ON”.
z 2 : This is displayed when the input signal is “DTS-ES Discrete
6.1”.
z 3 : This is displayed when the input signal is “DTS 96/24”.
For details, see page 79.
STANDARD :
This mode is for decoding the input signals according to their format
and playing surround sound.
The display when the STANDARD mode is selected depends on the
input signal and surround back output playback mode.
[Selectable items]
Playing Multi-channel Sources
(Dolby Digital, DTS, etc.)
41
Get
ting Star
ted
Connections
Set
up
Pla
ybac
k
Remot
e Contr
ol
Multi-Zone
Inf
or
mation
Tr
oubleshooting
DOLBY PLgx DTS NEO:6 neural
Surround Playback of 2-channel Sources
[Selectable items]
• When not using a surround back speaker
DOLBY PLg DTS NEO:6 neural
DOLBY PLgx
or DOLBY PLg
: The signals are decoded in DOLBY PLgx or
DOLBY PLg for playback.
Cinema
: This mode is suited for movie sources.
Music : This mode is suited for music sources.
Game : This mode is suited for games.
Pro Logic : This is the Pro Logic playback mode. This can
be selected when playing with a DOLBY PLg
decoder. When this mode is selected, “DOLBY
PL” is displayed.
DTS NEO:6
: The signals are decoded in DTS NEO:6 for
playback.
Cinema
: This mode is suited for movie sources.
Music : This mode is suited for music sources.
neural
: It is possible to play analog input signals and
PCM (2-channel, 48kHz or less) in the surround
mode.
This is the optimum mode for playing sources
recorded in XM HD Surround (vpage 76).
[Selectable items]
Standard Playback
This is the standard mode for enjoying surround sound
according to the program source.
Surround Modes
• When using a surround back speaker
To select these surround modes using the buttons on the main unit
and main remote control unit, press the STANDARD button. The mode
switches each time the button is pressed.
ON OFF
5s ~ 60s
XM
NET/USB
A1 Still Picture
Make settings for still picture (JPEG) playback.
Slide Show
Make slideshow settings.
Interval
Set the playback time per image.
Satellite
Indicate satellite signal strength.
Terrestrial
Indicate terrestrial signal strength.
A2 Antenna Aiming
Adjust the XM radio reception sensitivity.
[Selectable items]
[Input source]
[Input source]
[Variable range]
Display Condition
¡¡¡¡ Signal strength is strong
¡¡¡ Signal strength is good
¡¡ Signal strength is marginal
¡ Signal strength is weak
No signal
