26 DR ® STUMP GRINDER
Parts List – DRIVE ASSEMBLY (see page 24 for 9HP specific parts list)
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
01 265311 Engine, Subaru, 6HP, w/Labels
02 134431 Bolt, 5/16-18 x 1-1/2"
03 112381 Washer, Flat 1/4", Uss
04 110761 Nut, Nylon Lock, 5/16-18
05 265201 Clutch, Centrifugal, 3/4" Bore
06 178821 Bolt, Hcs, 5/16-24 x 1"
07 165141 Washer, .385" ID, 1.390" OD, 3/8" TH
08 264681 Belt, Stump Grinder, 6HP
09 265281 Guard, Belt, w/Labels
10 123211 Bolt, Hcs, 5/16-18 x 3/4"
11 112431 Washer, Lock, Split, 5/16"
12 257091 Label, Safety Icons
13 192391 Label, DR Logo, 5-3/4" Silver
14 265661 Arm, Idler Pulley
15 265351 Bolt, Shoulder, 1/2" x 3/4" Long
16 129691 Shim, .75"ID, 1.125"OD, .06"TH, ZP
17 112411 Washer, Flat, 5/16", Uss
18 264821 Deflector, Exhaust
19 180121 Pulley, Flat Idler, 3-1/4"
20 126861 Bolt, Hhcs, 3/8-16 x 2", Gr5
21 164131 Nut, Nylon Lock, 3/8-16, Low Profile
22 188871 Label, Hot Surface
Ref# Part# Description
23 164801 Spring, Ext, 3/4" OD, .085 Wire, 3" L
24 134431 Bolt, 5/16-18 x 1-1/2"
25 110691 Nut, 5/16-18, Zp, Gr2
26 265651 Pulley, 5" Diam, A/B Profile
27 258021 Bearing, Stamped Flange, 1" Bore
28 111581 Bolt, Hcs, 5/16-18 x 1", Gr5, Zp
29 264741 Guard, Pulley
30 264831 Ring, Retaining, 1" Shaft
31 265621 Base, Cutter Head, 2 Key
32 264641 Plate, Side, Cutter Head
33 160861 Bolt, Hhcs, 1/4-20 x 1-3/4", Gr8
34 110731 Nut, Nylon Lock, 1/4-20
35 264671 Tooth, Left
36 264651 Tooth, Straight
37 264661 Tooth, Right
38 142291 Key, Square, 1/4" x 1-1/4"
39 127811 Label, Warning, Check Oil
40 264851 Wire Harness
Not Illustrated
265321 Teeth Kit
