16 DR ® STUMP GRINDER
Replacing the Wheels
Tools and Supplies needed:
 1/2" Wrench
1. With the Stump Grinder on the ground, remove the Bolt, Lock Washer and
Large Flat Washer from the Axle with a 1/2" Wrench (Figure 21).
2. Block the Stump Grinder up so the Wheels are off the ground and remove
the Wheel.
NOTE: The Wheel on the right hand side has a Bushing in each end of the Wheel
Hub (make sure the Bushings are in place when installing the Wheel). The left hand
Wheel has a Keyway built in with a key to hold it from spinning when the Brake is
applied (make sure the Key is installed in the slot when installing the Wheel).
3. Reinstall the Wheel and secure with the Bolt, Lock Washer and large Flat
Washer using a 1/2" Wrench.
Tire
Figure 21
Bolt and
Washer
