24 DR ® STUMP GRINDER
Chapter 6: Parts Lists, Schematic Diagrams And Warranty
Parts List - HANDLEBAR ASSEMBLY
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
01 271731 Cross Member, Handlebar, w/Labels
02 134431 Bolt, 5/16-18 x 1-1/2"
03 110761 Nut Nylon Lock 5/16-18
04 265191 Label, Control Panel Front
05 179291 Plug, Control Panel, With Cutout
06 180691 Lever, Op Presence, w/ Wire
07 165181 Lever, Brake, w/ Lock
08 164951 Grip, Ergonomic, 1"
09 164961 Grip, 1"
10 264801 Throttle
11
111631 Screw, #10 x 1-1/2", Type A
12 265291 Handlebar, Right, w/Label
13 150431 Bolt, Hhcs, 3/8-16 x 1-1/4", Gr5
14 112411 Washer, Flat, 5/16", Uss
15 247291 Handlebar, Left
16 110751 Nut, Nylon Lock, 3/8-16
17 157121 Bolt, Hcs, 3/8-16 x 2-1/4", Full Thread
18 112141 Cable Tie, 7 1/2"
Ref# Part# Description
19 264791 Bracket, Brake Cable
20 179121 Bolt, Tri-Lobe, 1/4-20 x 1/2"
21 264761 Guard, Debris
22 111581 Bolt, Hcs, 5/16-18 x 1", Gr 5, Zp
23 112381 Washer, Flat, 1/4", Uss
24 271721 Frame, w/Labels
25 264881 Label, Head Rotation
26 234941 Label, DR Logo, 6" Round
27 235451 Label, CHP Address
28 264781 Cable, Brake
29 153451 Label, Throttle Control
30 217201 Meter, Hour/RPM/Maintenance
31 265041 Switch, Start
32 193201 Label, Start
33 235481 Keys
34
287011 Screw, M4 x 8mm
35 287021 Washer, Lock, M4
