4 0 0 S E R I E S O W N E R’S M A N U A L
400Rb Assembly Instructions
Frame and Seat Assemblies
1. Place the unit and all accompanying parts in a clean,
fl at, and open space.
2. Attach the Transport Bar to the front of the Frame
using two M10 x 20mm bolts.
3. Slide the Seat Track Support onto the lower bar of
the Frame and bolt it in place using four M8 x 15mm
bolts and four M8 washers.
4. Attach the Stabilizer Bar to the rear of the Seat Track
Support using two M10 x 20mm bolts.
5. Hold the Seat Track up to the frame horizontally with
the bolt holes facing to the sides. Slide the Seat Track
Cover and the Seat Frame onto the middle of the
Seat Track, checking to make sure they are oriented
right side up and facing the correct direction.
6. Slide the front of the Seat Track onto the upper
bar of the Frame, while placing the rear end of the
Seat Track into the upper arm of the Seat Track
Support. Attach the Seat Track to the Frame using
four M8 x 15mm bolts, with two M8 washers on the
front holes and two rubber stops on the rear holes.
Attach the Seat Track to the Seat Track Support
using two M8 x 15mm bolts and two M8 washers.
7. Slide the Seat Track Cover along the Track to the
Frame, and then thread the Hand Pulse Cable
through the Cover. Snap the Seat Track Cover into
place on the Frame by squeezing gently along the
sides, then press in fi rst the top two tabs and next
the bottom two tabs.
8. Place the Seat Handlebar on the Seat Frame
with the metal pulse grips facing upward and the
handles facing forward. Attach it in place using
four M8 x 10mm bolts and four M8 washers.
9. Place the Seat Pad on the Seat Frame with the
wide end at the back and attach it using four M6
x 45mm bolts. Hold the Seat Back against the Seat
Frame with the wide end down and attach it in
place using four M6 x 45mm bolts.
10. Stretch the free end of the Hand Pulse Cable along
the Seat Track to the back of the Seat and plug it
into the wires from the Seat Handlebar. Align the
Cable so that it will not be pinched by the Seat,
test by moving the Seat back and forth, and then
use the plastic zip tie provided to hold the wire
against the Seat in this safe position.
Console Mast Assembly
1. Hold up the Console Mast with the tube end facing
down and slide the Console Mast Cover onto it as
far as possible, with the tabs facing down.
2. Hold the Console Mast next to its mounting post
on the front of the Frame. Feed the wire harness
through the Console Mast so that it is attached
on the Frame end and the other end comes out
the top of the Mast.
3. Slide the Mast onto the mounting post.
Be careful not to pinch the wires while doing this,
doing so could cause the unit to malfunction.
Attach the Mast to the mounting post using three
M8 x 15mm bolts and three M8 arc washers (bent).
Carefully snap the Console Mast Cover into place
on the Frame.
4. Align the Handlebar with its post near the top of
the Console Mast so that only one bolt hole is facing
upward. Slide the handlebar onto the Mast and
attach it using three M8 x 15mm bolts and three M8
fl at washers.
Console Assembly
1.
Hold the Console up to the top of the Console
Mast and attach the wires from the top of the
Mast to the back of the Console. Carefully feed
the slack in the wires into the Console Mast, and
then place the Console on the mounting plate at
the top of the Console Mast.
Be careful not to
pinch the wires while doing this, doing so may
cause the unit to operate incorrectly.
2. Once the Console is in place on the on the Mast,
fasten it down using four M5 x 12mm bolts and
four M5 washers.
Pedal Assembly
1.
Use a 15mm open-end wrench to fi rmly affi x the
pedals to the cranks.
2. The left and right pedals are different and are
denoted as right or left (R or L) on the top and
bottom of each pedal.
Please NOTE: The Left
pedal threads pedal pedal counterclockwise.
3. Retighten the cranks after approximately 10
hours of use.
