400Ub Assembly Instructions

Frame and Seat Assemblies

1. Place the unit and all accompanying parts in

a clean, fl at, and open space.

2. Attach the Transport Bar to the Front of the

Frame using two M10 x 20mm bolts.

3. Attach the Stabilizer Bar to the rear of the

Frame using two M10 x 20mm bolts.

4. Loosen the seat pin by turning it counter

clockwise 1-2 turns. Install seatpost by sliding
into the seatpost receptor, pulling the seat
pin out until a suitable hole is found.

WARNING: Never mount the cycle unless the seat pin is fully & properly

engaged in the seat post.

5. Place the Seat on the rod at the top of the

Seat Post. Adjust the seat so that it is fl at and
pointing forward and then tighten the nuts
on the Seat’s bottom simultaneously using
two wrenches.

Console Mast Assembly

1. Hold up the Console Mast with the tube end

facing down and slide the Console Mast
Cover onto it as far as possible, with the
tabs facing down.

2. Hold the Console Mast next to its mounting

post on the front of the Frame. Feed the wire
harness through the Console Mast so that it
is attached on the Frame end and the other
end comes out the top of the Mast.

3. Slide the Mast onto the mounting post.

Be careful not to pinch the wire while
doing this, doing so could cause the unit to
malfunction.
Attach the Mast to the mounting
post using fi ve M8 x 15mm bolts and fi ve M8
washers. Carefully snap the Console Mast
Cover into place on the Frame.

4. Align the Handlebar with its post near the top

of the Console Mast so that only one bolt hole
is facing upward. Feed the wires from the
Handlebar up through the top of the Console
Mast. Slide the handlebar onto the Console
Mast while pulling gently on the wires to take
up the slack. Attach the Handlebar to the
Console Mast using three M8 x 15mm bolts
and three M8 fl at washers.

Console Assembly

1. Hold the Console up to the top of the Console

Mast and attach the wires from the top of the
Mast to the back of the Console. Carefully
feed the slack in the wires into the Console
Mast, and then place the Console on the
mounting plate at the top of the Console
Mast.

Be careful not to pinch the wires while

doing this, doing so may cause the unit to
operate incorrectly.

2. Once the Console is in place on the

on the Mast, fasten it down using four
M5 x 12mm bolts and four M5 washers.

Pedal Assembly

1. Use a 15mm open-end wrench to fi rmly affi x

the pedals to the cranks.

2. The left and right pedals are different and

are denoted as right or left (R or L) on the
top and bottom of each pedal.

Please NOTE:

The Left pedal threads

Left pedal

Left pedal

counterclockwise.

3. Retighten the cranks after approximately 10

hours of use.
