BIOS Setup

Frequency/Voltage Control

Phoenix - AwardBIOS CMOS Setup Utility

Frequency/Voltage Control

Item Help

Menu Level

↑↓→←

: Move

Enter: Select

F1: General Help

+/-/PU/PD: Value

F10: Save

ESC: Exit

F5: Previous Values

F6: Fail-Safe Defaults

F7: Optimized Defaults

CPU Clock Ratio Unlock

x CPU Clock Ratio

Disabled

8 X

The settings on the screen are for reference only. Your version may not be identical to

this one.

CPU Clock Ratio Unlock

Set this field to Enabled to unlock the CPU clock ratio. This will allow you to se-
lect the CPU clock ratio in the field below.

CPU Clock Ratio

This field is used to enter the CPU’s frequency ratio.
