BIOS Setup
OnChip IDE Device
Move the cursor to this field and press . The following screen will appear.
IDE HDD Block Mode
IDE DMA Transfer Access
On-Chip Primary PCI IDE
On-Chip Secondary PCI IDE
*** On-Chip Serial ATA Setting ***
x SATA Mode
On-Chip Serial ATA
x SATA PORT Speed Settings
x PATA IDE Mode
SATA Port
Phoenix - AwardBIOS CMOS Setup Utility
OnChip IDE Device
Item Help
Menu Level

↑↓→← : Move Enter: Select F1: General Help +/-/PU/PD: Value F10: Save ESC: Exit
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Enabled
Enabled
Enabled
Enabled
IDE
Auto
Normal
Primary
P1, P3 is Secondary
If your IDE hard drive
supports block mode
Select Enabled for
automatic detection of
the optimal number of
block read/writes per
sector the drive can
support
The settings on the screen are for reference only. Your version may not be identical to
this one.
IDE HDD Block Mode
Enabled
The IDE HDD uses the block mode. The system BIOS will check the hard disk
drive for the maximum block size the system can transfer. The block size will
depend on the type of hard disk drive.
Disabled
The IDE HDD uses the standard mode.
IDE DMA Transfer Access
This field is used to enable or disable the DMA transfer function of an IDE
hard drive.
