Matrix-1000™
48
6
READING FEATURES
Frame rate
up to 30 frames / sec
Pitch
10° - 35°
Readable codes per frame
up to 100
Tilt
0° - 360°
Reading
Distance
(3)
mm (in)
MODELS
Focus
Distance
mm (in)
Field of
View
(1)
mm (in)
ppi
(2)
Typ. Linear
and
Stacked
Code
Resolution
mm (mils)
Typ. 2D
Code
Resolution
mm (mils)
min.
max.
1021 HD
115 (4.52)
25
Ч
19
(0.98
Ч
0.75)
653 0.10
(4)
0.19 (7.5)
105
(4.13)
125
(4.92)
1031 SD
155 (6.10)
34
Ч
26
(1.34
Ч
1.02)
478 0.15
(6)
0.25 (10)
135
(5.31)
180
(7.08)
1041 LD
110 (4.33)
54 x 40
(2.13
×
1.57)
300 0.20
(8)
0.38 (15)
90
(3.45)
140
(5.51)
1051 MR
210 (8.26)
95
Ч
70
(3.74
Ч
2.75)
170 0.30
(12)
0.60 (24)
150
(5.90)
250
(9.84)
(1)
@ focus distance
(2)
Pixels per inch @ focus distance
(3)
Measurement conditions:
•
Test chart: provided with the reader
•
Still code at the center of the FOV
•
Code symbology:
Data Matrix ECC 200
•
Code resolution: Typ. 2D Code Resolution
•
Tilt angle: 45°
•
Pitch angle: 15°
•
Decode mode: Predictable
