Chapter 7 BIOS Setup
Chapter 7
If AHCI or RAID is selected in the SATA Mode field, it will display the following information:
Aggressive LPM Support
Enable PCH to aggressively enter link power state.
SATA Controller Speed
Indicates the maximum speed the SATA controller can support.
Serial ATA Port 0 to Serial ATA Port 5
These fields are used to configure the connected SATA devices.
Determines how SATA
controller(s) operate.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
SATA Controller(s)
SATA Mode Selection
Aggressive LPM Support
SATA Controller Speed
Serial ATA Port 0
Software preserve
Port 0
Hot Plug
External SATA
SATA device type
Spin up device
Serial ATA Port 1
Software preserve
Port 1
Hot Plug
External SATA
SATA device type
Spin up device
Serial ATA Port 2
Software preserve
Port 2
Hot Plug
External SATA
Spin up device
Serial ATA Port 3
Software preserve
Port 3
Hot Plug
External SATA
Spin up device
Serial ATA Port 4
Software preserve
Port 4
Hot Plug
External SATA
Spin up device
Serial ATA Port 5
Software preserve
Port 5
Hot Plug
External SATA
Spin up device
Advanced
[Enabled]
[AHCI]
[Enabled]
[Gen3]
Empty
Unknown
[Enabled]
[Disabled]
[Disabled]
[Hard Disk Driver]
[Disabled]
Empty
Unknown
[Enabled]
[Disabled]
[Disabled]
[Hard Disk Driver]
[Disabled]
Empty
Unknown
[Enabled]
[Disabled]
[Disabled]
[Disabled]
Empty
Unknown
[Enabled]
[Disabled]
[Disabled]
[Disabled]
Empty
Unknown
[Enabled]
[Disabled]
[Disabled]
[Disabled]
Empty
Unknown
[Enabled]
[Disabled]
[Disabled]
[Disabled]
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit


Intel TXT (LT) Configuration
This section is used to configure the Intel Trusted Execution technology.
Intel TXT(LT) Support
The options are Enabled and Disabled.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Intel Trusted Execution Technology Confi guration
Intel TXT support only can be enabled/disabled if SMX
is enabled. VT and VT-d support must also be enabled
prior to TXT.
Secure Mode Extension (SMX)
Intel TXT(LT) Support
Advanced
Enabled
[Disabled]
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
