Troubleshooting 17
Section 4: Troubleshooting
The Daktronics All Sport CG connects a control console and video equipment with a device used to
record and display the information. To do this properly, the devices must be connected correctly.
A combination TV/VCR works well as a recording device because it allows the operator to view the
final output as it is recorded. By seeing the output on screen, the operator knows instantly if there is
not a proper connection and what part of the system is not working.
Use the following suggestions to troubleshoot some of the more common problems that may occur
with the All Sport CG system:
Problem Possible Solution
All Sport CG does not turn on  Ensure the transformer is plugged into the wall
outlet and connected to the All Sport CG
 Ensure the wall outlet has power (breaker not off)
Video feed does not show on
the output  Check the connection between the video source and
the All Sport CG
 Check the connection between the All Sport CG and
the recording device
 Ensure the video equipment is ON and working.
Refer to the video equipment user’s manual for
further troubleshooting.
Video does not record  Ensure the recording device is ON and working.
Refer to the recording device user’s manual for
further troubleshooting.
 Ensure that the video media is not copy protected.
Game-in-progress information
does not show on the output  Check the wired or wireless connection between the
All Sport controller and the All Sport CG if in
Automatic mode.
 Ensure the All Sport CG is set to a sport whether in
Manual or Automatic mode.
 Ensure the All Sport controller is ON and a code
number has been entered.
4.1 Replacement Parts
Part Description Part Number
All Sport CG Inserts LL-2612
Cable; 20', 9 pin-D-Female to ¼" Phono 0A-1196-0146
Cable, RCA Male-to-Male, 6' W-1219
Transformer; 12 VAC T-1118
