Operation 7
OVERLAY LOCATI ON
ENTER TO MODI FY
LOOKI NG FOR
ALL SPORT
TEAM SCORE: +1
HOME 7
TI ME 8:00
SELECT ALT I TEM TEAM SCORE: -1
HOME 6
TI ME 8:00
SELECT EDI T I TEM TEAM SCORE: EDI T
HOME ^^6*
Overlay Location
By default, scoring information from the All Sport CG is
displayed across the top of the video output. To change this
location, press and press <↑> and <↓> to
toggle between Very Top, Top, Bottom, and Very Bottom.
Press again to save.
3.2 Automatic Mode
Operation of the All Sport CG is simple when connected to an All Sport controller. The All
Sport CG receives game data via wire or wireless radio from the control console and overlays
it onto the video feed in real time. The All Sport CG is automatically set to the same sport as
the control console and all information is received directly from it.
When the All Sport CG is set to Automatic mode, it will
search for a signal from the All Sport controller. If the
controller is not connected, the LCD displays the message:
The only direct operation required is configuring the Broadcast Group and Channel Number
for use with a radio control console. Refer to Section 2.4 and the appropriate All Sport
controller operation manual for more information.
3.3 Manual Mode
When using Manual mode, the All Sport CG does not have an external source for game data,
so all information must be entered by hand with the keypad. The All Sport CG uses
removable inserts to denote which button has what function for the particular sport mode.
The buttons that apply to all sports include
Scoring
Each sport has two to six buttons on the keypad insert used
for keeping score. Press these buttons to increment, or add
to, the score by the value printed on the insert.
To decrement, or subtract, points from the home team, press then SCORE +1/-1>. To decrement points from the guest team, press then
. Only one point can be subtracted from either team at a time.
The score can also be edited by pressing followed by any of the scoring
buttons. Use the keypad to type in the value, and then press again to save.
