Chapter 3. SYSTEM OPERATION
3.1 Pin-outs..............................................3–1
3.2 Turning On the CSAT ........................3–3
3.3 Configuring the CSAT ........................3–3
This section contains instructions for operating the CSAT-6070, 5 to 25 Watt Mode
C-Band Transceiver. The Primary customer interface to the CSAT is via the Remote
Communications port. Appendix A provides details regarding the protocol and
command/response structure used on this interface. This section will define in detail the
controllable parameters provided via the command/response structure.
3.1 P
IN
-
OUTS
3.1.1 C
ONNECTOR
J3: AC P
OWER
, M
AINS
, 100
TO
125 VAC,
OR
205
TO
240
VAC.
WARNING
To avoid a serious shock hazard, correctly determine the mating
connector type in use and wire it according to the following table:
EARLY UNITS NEWER UNITS
Pin Mating Connector Type
KPT06J12-3S
MS3116J12-3S
Mating Connector Type
CA3106E18-22SB
A Line Ground
B Ground Neutral
C Neutral Line
