Appendix C. MAINTENANCE AND
TROUBLESHOOTING
C.1 Maintenance Testing .................................... C–1
C.2 Troubleshooting ........................................... C–2
C.3 Converter Faults ........................................... C–2
C.4 Equipment Return and Repair Procedure .. C–4
C.5 Product Application, Upgrading or Training
Information ................................................... C–4
This appendix is intended to provide procedures to assist operator and maintenance
personnel in the checkout, maintenance and troubleshooting of the transceiver. Comtech
EF Data recommends that spare replacement transceivers be used to replace transceivers
removed from the system for maintenance. The input and output signals, the
interconnecting cables and the location of the modules are as shown in Figure C-1.
Figure C-1. Converter Signal and Interconnecting Cable Diagram
C.1 M
AINTENANCE
T
ESTING
Use the instructions in Chapter 2 for installing the transceiver for checkout, and the
procedures in Chapter 3 , for operating the transceiver.
