5 to 25 Watt Model C-Band Transceiver Revision 0
Introduction MN/CSAT6070.IOM
1.1 F
UNCTIONAL
D
ESCRIPTION
The Transceiver is designed for use in communication systems, or in satellite up-link data
systems, for the reception of SCPC DAMA, and TDMA communication signals. It can
also be used in communications system applications with full transponder HDTV and
analog TV.
The converter is environmentally sealed and is designed to be hard mounted on or near
the antenna structure. A covered cooling fan is mounted on the outside of the unit to
maintain a reduced operating temperature for enhanced reliability.
WARNING
The Downconverter RF input connector is wired to supply DC voltage to an LNA.
This voltage is capable of damaging any test equipment connected to the
connector. Do not connect test equipment to this connector without a coaxial DC
block between the connector and the test equipment.
1-2
