Product overview
Technical data
Technical data EL9200 EL9210 EL9290
Nominal voltage 24 V
DC
variable, up to 230 V AC
Power contact current load max. 10 A
Electrical isolation yes
Integrated fine­wire fuse yes; 6.3 A
Current consumption from E­
Bus ­ typ. 90 mA ­
Bit width in the process image ­ 1 bit (diagnosis) ­
Configuration no address or configuration settings
Power LED yes yes no
Diagnosis (fuse) yes, Error LED yes, in process image
and ErrorLED no
Electrical connection to
mounting rail no
PE contact yes
Weight approx. 55 g
Permissible ambient
temperature range (during
operation) 0°C ... +55°C
Permissible ambient
temperature range (during
storage) ­25°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15 mm x 100 mm x 70 mm (width aligned: 12 mm)
Mounting [ } 60] on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance conforms to EN 60068­2­6/EN 60068­2­27
EMC resistance burst/ESD conforms to EN 61000­6­2/EN 61000­6­4
Protect. class IP 20
Installation pos. variable, see chapter
"Mounting of Passive
Terminals [
} 70]"
variable variable, see chapter
"Mounting of Passive
Terminals [
} 70]"
Approval CE
ATEX [
} 71]
cULus [ } 74]
CE
Connection EL9200, EL9210, EL9290
CAUTION
Hazard to individuals and devices!
When designing a Bus Terminal block with different potentials on the power contacts (e.g.
230 V AC and 24 V DC), please note that it is mandatory to use potential separation termi­
nals (EL9080)!
Bring the bus system into a safe, powered down state before starting installation, disas­
sembly or wiring of the Bus Terminals!
