SPBD-155E4J1RD

DELTA ELECTRONICS, INC.

3 Revision:

S1

04/11/2007

www.deltaww.com

4. Specification of Receiver

Parameter

Symbol

Min.

Typ.

Max.

Unit

Note

Input Optical Wavelength

λ

IN

1480 1600 nm PIN-PD

Receiver Sensitivity

P

IN

-31

dBm Note

(1)

Input Saturation Power (Overload)

P

SAT

-3 dBm

LOS-Deassert Power

P

A

-

-31

dBm

LOS-Assert Power

P

D

-44 dBm

Note

(2)

LOS Hysteresis

P

A

-P

D

0.5 2 5 dB

Optical Reflectance

-14

dB

Note (3)

Output Data Rise/Fall time

t

r

/t

f

1.5

ns

Note

(4)

S/X Endurance

10

dB

Note (5)

Optical Isolation

25

dB

Note (6)

Note (1). Measured with 1520nm, ER=10dB; BER =<10

-10

@PRBS=2

23

-1 NRZ

Note (2). When LOS asserted, the data output is Low-level (fixed)
Note (3). When the terminal is viewed from the optical path, the reflection toward the optical path of the

optical signal with a central wavelength of 1480nm to 1580nm transmitted to terminal.

Note (4). These are 20%~80% values

Note (5). X=10 MHz, Rectangular BER =10

-10

Note (6). Receiver isolation between 1260nm ~1360nm

5. Electrical Interface Characteristics

Parameter

Symbol

Min.

Typ.

Max.

Unit

Note

Transmitter
Total Supply Current

I

CC

A

mA

Note

(1)

Differential Data Input Swing

V

DT

500 2400

mV

p-p

Differential line input Impedance

R

IN

80

100

120

Ohm

Transmitter Disable Input-High

V

DISH

2 V

CC

V Note

(2)

Transmitter Disable Input-Low

V

DISL

0 0.8 V

Transmitter Fault Output-High

V

TXFH

2

V

CC

+0.3

V

Transmitter Fault Output-Low

V

TXFL

0 0.8 V

Transmitter Fault Pull up Resistor

R

TX_FAULT

4.7

10

kΩ Note

(3)

Receiver
Total Supply Current

I

CC

B

mA

Note

(1)

Differential Data Output Swing

V

DR

400 2000

mV

p-p

Note

(4)

LOS Output Voltage-High

V

LOSH

2

V

CC

+0.3

V

LOS Output Voltage-Low

V

LOSL

0 0.8 V

Receiver LOS Load

R

RXLOS

4.7 10 kΩ Note

(3)

Note (1). A (TX)+ B (RX) = 300mA

(A: Not include termination circuit; B: using a resister of 150Ω between Data-output and ground)

Note (2). There is an internal 4.7 to 10kΩ pull-up resistor to VccT.
Note (3). Pull up to V

CC

on host Board.

Note (4). Internally AC coupled with LVPECL output, but requires a 100Ohm differential termination at or

internal to Serializer/ Deserializer.
