Users Manual LOKPRINT™ Mechanical Assembly Drawings •••• 25
Optional Heater Parts List
ITEM PART NO. Description QTY
1 991040 10-32 x 3/4 Cap screw (ss) 4
2* 101103 Heat element 120v 200 Watt
1
3** 221129 Heat element 120v 250 Watt 1
4*** 221130 Heat element 120v 300 Watt 1
5 101102 Thermocouple 2
6 191116 Insulated bushing 1
7 221016 Heat deflector 1
8 221007 Heater base 1
9 365030 Spacer 4
10 221091 Heater block assy 1
11 990067 Washer, #8 SAE 4
12 990196 10-32 x 1/2 Flat head screw 2
13 990108 10-32 x 1/2 Truss head screw 2
14 990728 Washer, #10 Lock 4
*Item 2 – Use Part No. 101104 for 240V Machine
**Item 3 – Use Part No. 221131 for 240V Machine
***Item 4 – Use Part No. 221132 for 240V Machine
