Dell CDPR3 - Manual (Page 26)

11. When prompted, press the Disc button to print the following test pattern on a disc.
12. The black and magenta lines should be straight as shown above. If they are not
inline with each other, repeat the alignment process starting at step 5.
13. Close the Align Cartridges window.
14. Close the Printing Preference window.
15. Select the Disc button to close the printer tray. If the printer tray does not close,
close the tray controller application and open it again. Wait for the tray controller
to initialize, about 60 seconds, and press the Disc button to close the tray.
16. If you are installing the equipment, go to step 4 of the “ Check Printer Tray
Alignment to the Picker ” section, to complete installation.
Installation 26
