Install Ink Cartridges
The printer is shipped without ink cartridges installed. Before installing the ink
cartridges in the Liberty printer, allow the cartridge to reach room temperature before
installing it. Store ink cartridges at a temperature between 50–90°F (10–32 °C) and
avoid moisture and direct sunlight.
1. With the power still on, open the top cover. The ink cartridge cradle moves into
position to install the ink cartridges.
1 – Top Cover 2 – Cradle Latches 3 – Cartridge Cradle
2. Raise the cradle latches.
3. Remove each ink cartridge from its packaging.
4. Carefully remove the plastic tape. Hold the ink cartridge so that the copper strip is
on the bottom (see below). Do not remove the copper strips and do Not touch the
ink nozzles!
1 – Plastic Tape 2 – Ink Nozzles 3 – Copper Strip 4 – Ink Cartridge
Installation 22
