5. Install the ink cartridge into the cartridge cradle so the label is facing toward you.
Caution: The black ink cartridge can be damaged when installing it in the printer. Use
minimal force when installing the Ink cartridge; it takes little pressure to install
an ink cartridge.
1 – Cradle Latch 2 – Ink Cartridge 3 – Label
6. Push the ink cartridge firmly into position and secure the cradle latch.
7. Install the other ink cartridge using the same procedure.
8. Close the top cover.
For best prints, the cartridges must be aligned after installation or replacement. For
more information about cartridge alignment, see “ Align Ink Cartridges ” section next.
Align Ink Cartridges
For optimal print quality, align the ink cartridges using the steps below.
1. Windows 2000 – Select the Windows Start button and select Settings|Printers.
Windows XP – Select the Windows Start button and select Printers and Faxes.
2. Right-click on the Disc Color Printer and select Printing Preferences from
the drop-down menu.
23 Installation
