Figure 26. configuring the debug options – Zilog Z51F3221 User Manual
Page 37
UM025801-1112
Using the Keil µVision IDE on a Demo Project
Z51F3221 Development Kit
User Manual
30
When configuring the appropriate Debug option, be aware of the following stipulations:
•
Checking the
Peripheral continues running
option means that the timers used in
your project will run while the processor is stopped by the debugger.
•
The
Reset at Main
option will only work if you have a
main
file in your project; oth-
erwise you should deselect this option.
8. Click the
Flash Options
tab. The Flash Options Settings dialog will appear, as shown
in Figure 27. To select the proper options for Flash programming, refer to the
.
Figure 26. Configuring the Debug Options
Notes:
