Front Panel Control and Connections
Front Panel Control and Connections
Front Panel Controls
Power toggle / extended setup button.
Window for IR sensor.
Clear button and memory buttons.
Input selection buttons 1-8.
Enter button.
Audio / video breakaway selection button.
Zone selection buttons 1-8.
Power indicator / IR received.
Audio / video breakaway LEDs.
Current input mappings for each zone.
AUDIO VIDEO MATRIX SWITCH
AUD
VID
MEM 1 2 3 4
CLR 5 6 7 8 ENT 1 2 3 4 5 6 7 8
C
A
B
G
F
K
J
D
E
H
A
B
C
D
E
F
G
H
J
K
