22 ClarityHD8x8 Serial Protocol, Version 1.1, 6/7/13
Advanced Control
Advanced Control
Reference for Advanced Control Commands
These commands are for more advanced control over the ClarityHD8x8, including front panel light
intensities, changes to serial port behavior, etc.
Advanced Control Commands
Advanced Command Definitions
‘!’ Resend Error Code
This special purpose command is used to request that the ClarityHD8x8 resend the last error code sent.
This can be useful if the last error code sent had a checksum appended to it that did not match.
^!$ Request that the last error code sent, be resent
‘V’ Version
Returns the current firmware version of the ClarityHD8x8.
^V ?$
Response String:
^=V “ClarityHD8x8”,1.0a,30B2S12345678$
Where:
“Clarity 8x8” = Model
1.0a = Firmware version
30B2S12345678 = Serial number
‘QI’ Query for Zone, Input and Channel Information
Returns the number of zones, and inputs, and a mask of the channels available on the ClarityHD8x8.
^QI ?$
Response String:
^=QI zones,inputs,chan_bitmap$
Command Description Comments
! Get most recent error code Returns: Most recent error code, or error code 0’ if no error.
V ? Get version string Returns: Product name and firmware version string.
LI mode,dim,bri,off Sets LED intensities mode=Mode (0=off, 1=dim, 2=bright, 3=auto), dim,bri,off=Dim, Bright and Off levels (0-100).
QI ? Query for capability information Returns: Number of zones & inputs, and a full channel mask.
XS flags Control settings Set / reset control options. flags=Control option flags (see text).
XE flags Transmit enable flags Enable commands to asynchronously send there status. flags=Enable flags (see text).
SS flags Save Settings Save specified settings as initial power on values. flags=Indicate which settings to save.
IPA xxx,xxx,xxx,xxx View or change TCP/IP address View the current address, or change it.
FS 246 Reset to factory settings Resets ALL values to initial factory settings!
Table 2: Advanced Control Commands
