26 ClarityHD8x8 Serial Protocol, Version 1.1, 6/7/13
Advanced Control
‘FS’ Reset to Factory Settings
This command will reset selected parameters of the ClarityHD8x8 to their factory default settings.
This command uses a bitmapped parameter to indicate which values are to be reset. A bit set to ‘1’
indicates the associated setting should be reset, a bit set to ‘0’ indicates the setting should not be reset
and the previous setting will remain unchanged.
Command formats:
^FS settings$ Reset the parameters indicated by ‘settings’
Response String:
There is no response string to the FS command, this command is write only.
Where ‘settings’ is a bitmapped parameter defined as:
Bit-0 - Reset zone input/output mappings, and power state
Bit-1 - Reset switching delay times
Bit-2 - Reset LED levels and mode
Bit-3 - Reset control settings (the XS command settings)
Bit-5 - Reset IP parameters
Bit-15 - Reset HDMI settings: Clear EDID and HDCP caches, clear HDCP key counts and the EDID lock state.
Note: The ClarityHD8x8 must be turned on before sending the “Reset HDMI settings” (Bit-15), and
the switch must be power cycled (using the ‘P 0’ and ‘P 1’ commands) before the cleared settings take
affect.
All other bits are reserved and should be set to 0 when issuing this command.
‘LI’ Lighting Mode and Intensities
This command uses a bitmapped parameter. Each bit can set or reset without affecting the other bits.
(See: “Using Bitmapped Parameters” on page 17, for more information on using bitmapped parame-
ters.)
Allows changing the behavior of the front panel LEDs, and adjusting their intensities.
^LI mode,dim,bright,off$ Set mode and intensities
^LI ?$ Query for current settings
Response String:
^=LI mode,dim,bright,off$ Set mode and intensities
Where:
mode = Lighting mode (Settings: 0=Off, 1=Dim, 2=Bright, 3=Auto-dim)
dim = Intensity of dimmed LEDs (Range: 0-100)
bright = Intensity of brightened LEDs (Range: 0-100)
off = Intensity of the standby power LED (Range: 0-100)
Response Example:
^=LI 3,020,090,010$ Mode=Auto, dim=20%, bright=90%, off=10%
The mode settings allow you to set the front panel LEDs to always be: 0 - off, 1 - Always at the ‘dim’
intensity, 2 - always at the ‘bright’ intensity, or 3 - auto-dim from ‘bright’ to ‘dim’ when the front panel
is not in use.
The intensities range for 0, which of off, to 100, which is full intensity.
Value 32768 16384 8192 4069 2048 1024 512 256 128 64 32 16 8 4 2 1
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
