6 Multi Format LCD Monitor
●
Compatible with varied SDI signals
- The product is compatible with varied
SD/HD/3G(A/B)-SDI 480i,576i,720p,1080i/p,
1080psf.
●
Compatible with analog signals
- The product is compatible with analog
signals - Composite
●
HDMI/DVI Digital(HDCP) / Analog input
support
- HDMI, DVI digital/analog(VGA) input is
available without any other accessories.
●
All-in-one type system
- Slim and all-in-one type monitor that
requires no other accessories and optimized
for space utilization.
●
Waveform/Vector Scope/Luma(Y’) zone
check/Audio Level Meter support
- Waveform & Vector Scope support
- Luma(Y’) zone check support(False color)
- Embedded Audio Level Meter support
●
Luma(Y’) zone check(Color/Zebra type)/
Range error function
●
Audio in & out
- built-in internal speaker (Embedded audio &
External audio in)
- Stereo audio out using phone jack & external
audio in.
●
Knob Control
- Easy to adjust user configuration using the
control knobs.
●
BLUE ONLY/MONO/Focus-Assist/H/V delay
●
Internal pattern generator(0~100% Gray/
Colorbar+Pluge)
●
Varied Markers & Safety Areas
- Center Marker, Safety Area Marker, Aspect
Marker, Display Size(Scan)
●
1:1 SCAN / Zoom
- Outputs the original signal image on the
screen without scaling.
- Outputs the original signal image with
zoom-in.
- Zoom scroll function (left/right/up/down).
●
Wide screen compatible
- Wide screen for 16:9 aspect monitoring.
(LVM-170A/LVM-176W / 182W-A)
- Native Wide screen for 16:9 aspect
monitoring. (LVM-232W-A / 246W)
●
AC/DC Compatible
- Basically, this product is powered by a
normal AC source, and is also compatible
with DC.
- DC 12V : LVM-246W
●
Remote control function
- The product can be remotely controlled
using external switch or RS-422
communication.
●
RS422/UMD feature support
- This product supports protocols provided by
TVLogic or a TSL protocol.
●
Additional Features
- Wide Viewing Angle, Loop Through (SDI/
Analog), VESA mounting, Easy to operate
OSD user interface, Rack Mountable Design.
- LVM-170A : 700:1 contrast, 300cd/㎡
Brightness
- LVM-182W-A/232/246W : 1000:1, 300cd/㎡
Brightness
- LVM-176W : 900:1, 350cd/㎡
LVM-170A/176W/182W-A/232W-A/246W Monitors contain the following features:
2. Main Features
