Thor 1- 4 HDMI to QAM Modulators - Manual (Page 34)

H-4SDI-or-4HDMI-QAM-IP
 Keyboard and LCD Lock: If it is marked with “√”，the LCD and keyboard will be
locked to avoid unrelated users’ modifying or view the device information and
configurations. User can’t operate the keyboard & LCD while only the device IP
address can be noted in the LCD window.
Backup/Load
Click “Backup/Load” from the menu, it will display the screen as Figure-15.
Backup Configuration – To back up the device configuration file to a folder
Load Configuration – If user needs to load the old configuration to the device, click
“Browse” and find the backup configuration file path. After selecting the file, click
“Load File” to load the backup file to the device.
Figure-15 Browse
Button
IP Address
192.168.000.136
