Signamax
 Hardened PoE Ethernet Switch
6 User’s Manual
Preface
This manual describes how to install and use the Signamax

Hardened PoE Ethernet Switch. A member of the growing
family of rugged switches, this Hardened PoE Ethernet
Switch provides an affordable solution for rugged and
outdoor environment, transportation road-side cabinet,
industrial floor shop, multitenant dwellings or Fiber To The
Home (FTTH) applications. Capable of operating at
temperature extremes of -40℉ to 167℉ (-40℃ to 75℃), this
is the switch of choice for harsh environments.
Port 1 to port 16 on this Switch supports IEEE802.3at Power
over Ethernet (PoE) Power Sourcing Equipment (PSE) and
can detect an IEEE802.3at compliant Powered Device (PD).
Using external 47~57VDC power inputs through Terminal
Block, data and power can be transmitted to a Powered
Device (PD) over the same twisted-pair Ethernet cable
through port 1 to port 16 on the Switch.
This manual describes how to install and use the hardened
Ethernet Switch. This switch integrates full wire speed
switching technology. This switch brings the answer to
complicated hardened networking environments.
To get the most out of this manual, you should have an
understanding of Ethernet networking concepts.
In this manual, you will find:
• Product overview
• Features on the Switch
• Illustrative LED functions
• Installation instructions
• Specifications
