Signamax

Hardened PoE Ethernt Switch

User’s Manual

3

LED

State

Indication

Power1
Power2

Steady

Power on.

Off

Power off.

Fault

Steady

Power redundant system failure occurred.

Off

Power redundant system failure is not occurred.

10/100BaseTX

Link/ACT

Steady

A valid network connection established.

Flashing

Transmitting or receiving data.
ACT stands for ACTIVITY.

10/100

Steady

Valid port connection at 100Mbps.

Off

Valid port connection at 10Mbps.

PoE

Steady

Powered device (PD) is connected.

Off

Powered device (PD) is disconnected.

LED

State

Indication

Gigabit Ethernet

Link/ACT

Steady

A valid network connection established.

Flashing

Transmitting or receiving data.
ACT stands for ACTIVITY.

TX

Steady

A valid TX connection established.

Off

No valid TX connection established.

SFP

Steady

A valid SFP connection established.

Off

No valid SFP connection established.


DC Terminal Block Power Inputs: There are two pairs of
power inputs can be used to power up this switch.
Redundant power supplies function is supported.

Power Input Assignment

Power2

47-57VDC

Terminal Block

Power Ground

Power1

47-57VDC

Power Ground

Earth Ground

Relay Output Rating

1A @ 24VDC

The 10/100BaseTX (PoE) and Gigabit Ethernet Connectors

1. The 10/100BaseTX (PoE) Connections

The following lists the pinouts of 10/100BaseTX ports.
