Signamax
 Hardened PoE Ethernet Switch
12 User’s Manual
There are two pins on the terminal block are used for power
failure detection. Use this as a dry contact application to send
a signal for power failure detection.
Power Input Assignment
Power2
＋ 47-57VDC
Terminal Block
－ Power Ground
Power1
＋ 47-57VDC
－ Power Ground
Earth Ground
Relay Output Rating 1A @ 24VDC
Connecting to Your Network
Cable Type & Length
It is necessary to follow the cable specifications below when
connecting the switch to your network. Use appropriate
cables that meet your speed and cabling requirements.
Cable Specifications
Speed Connector Port Speed
Half/Full
Duplex Cable Max.
Distance
10BaseT RJ-45 10/20 Mbps 4-pair UTP/STP
Cat. 3, 4, 5 100 m
100BaseTX RJ-45 100/200 Mbps 4-pair UTP/STP
Cat. 5 100 m
1000BaseT RJ-45 2000 Mbps 4-pair UTP/STP
Cat. 5 100 m
1000BaseSX SC, ST 2000 Mbps MMF (50 or
62.5μm)
275, 550 m
1000BaseSX SC 2000 Mbps MMF (50 or
62.5μm)
2 km
1000BaseLX SC 2000 Mbps SMF (9 or 10
μm)
10, 20 km
1000BaseBX SC 2000 Mbps SMF (9 or 10
μm)
20 km
SFP
1000BaseSX
Duplex LC 2000 Mbps MMF (50 or
62.5μm)
275 m, 550
m, 2 km
1000BaseLX Duplex LC 2000 Mbps
SMF (9μm)
10, 20, 40,
70 km
1000BaseBX Single LC 2000 Mbps MMF (50 or
62.5μm)
550 m
1000BaseBX Single LC 2000 Mbps
SMF (9μm)
10, 20 km
