Preface
065-1800 series Hardened Media Converter
User’s Manual
1
Preface
This hardened media converter provides an affordable solution for rugged
and outdoor environments, transportation roadside cabinets, industrial
floor operations, multi-tenant dwellings, or Fiber To The Home (FTTH)
applications.
It is the media converter of choice for harsh environments
with space constraints. It is capable of operating at temperature extremes
of -
40° F to 165° F (-40° C to +74° C).
Plug-and-Play Solution:
The Signamax 065-1800 series hardened media converter is a plug-and-
play media converter with a compact case size. There is no complicated
software set up required.
This manual describes how to install and use the Signamax 065-1800 series
hardened media converters with the Link Fault Signaling (LFS) function.
The converters introduced here provide one channel of media conversion
between 10/100BaseT/TX and 100BaseFX connections.
These converters fully comply with IEEE802.3 10BaseT and IEEE802.3u
100BaseTX/FX standards.
In this manual, you will find:
Product overview
Features of the 065-1800 series media converters
Illustrative LED functions
Installation instructions
Specifications
