SATA Configuration

This section is used to configure the SATA drives.

SATA Controller(s)
Enables or disables the SATA controller.

SATA Mode Selection
Configures the SATA as IDE or AHCI mode.

IDE

This option configures the Serial ATA drives as Parallel ATA

physical storage device.

AHCI This option configures the Serial ATA drives to use AHCI

(Advanced Host Controller Interface). AHCI allows the storage

driver to enable the advanced Serial ATA features which will

increase storage performance.

Port 0
Enables or disables Serial ATA port 0.

Spin Up Device
Enables or disables staggered spin up on device connected to Serial ATA
port 0.
