Chapter 3: System Setup
NViS 3540/3540H/3540P4/3540P8 and NViS 3542/3542H/3542P4/3542P8 User Manual
Installing a SATA Hard Drive
1. With the bottom side of the chassis facing up, remove the screws of
the bottom cover.
2. Remove the 4 mounting screws that secure the drive bay to the chassis.
If you are installing one SATA drive only, the system will allow you
to install an optional CompactFlash card, a half length SATA DOM
or a full length SATA DOM.
3. Remove the drive bay. The drive bay is used to hold a SATA hard drive.
