Chapter 2: Jumpers and Connectors
NEX 608 User Manual
COM4 RS232 RI# Power Select
Connector size: 1x5 5-pin header, 2.54 mm pitch
Connector location: JP16
1 5
Pin Definition
1-2 On +5V
2-3 On +12V
4-5 On Enable
5 Disable
4-5 On: default
RTC Clear
Connector size: 1x3 3-pin header, 2.0 mm pitch
Connector location: JP6
1 3
Pin Settings
1-2 On Normal
2-3 On CMOS Clear
1-2 On: default
Pin Definition
1 NA
2 VCC3P3RTC
3 BATT_GND
