Junger Audio C8621- Dolby® D/D+/E Decoder & Metadata Generator - Manual (Page 2)

digital audio
modular
processing system
C8000
Dolby
®
E / D / D plus decoder
C8621
Page 2/19
Technical data:
Standards Decoder for compressed multichannel audio supporting proprietary Dolby
®
formats.
Audio Formats PCM (24bits)
Dolby
®
Pro Logic II
Dolby
®
E (16/20 bits, video frame rates: 23.975, 24, 25, 29.97, 30fps)
Dolby
®
D
Dolby
®
D+ (Audio Description supported)
Audio Channels 8 inputs (2 compressed or up to 8 PCM)
12 outputs (8 decoded audio + 2 downmix + 2 delayed)
Channel Modes up to 7.1
Audio Sample Rate 48kHz
Audio Delay 0 … 340ms for 2 channels, user settable and routable
Relevant specifications comply with AES3-X-2009, IEC 60985 and
AES11-2009
2 channels (1 stereo input), BNC connector
24bits, PCM or compressed audio, decoder input
Impedance 75Ohm
AES/EBU Input
(External)
Input level 0.3 … 5Vpp @ 75Ohm single-ended
Relevant specifications comply with AES3-X-2009, IEC 60985 and
AES11-2009
2 channels (1 stereo output), BNC connector
24bits, PCM audio, downmix / Pro Logic II, decoder output
Impedance 75Ohm
AES/EBU Output
(External)
Output voltage 1Vpp (typ.) @ 75Ohm single-ended
Relevant specifications comply with SMPTE RDD6-2008 (Dolby
®
Metadata).
Connector type D-Sub9 connector female
Metadata Output
(External)
Output conditions 3Vpp (typ.) @ 110Ohm differential, RS485,
115kbaud
Dolby E 1 video frame, depending on signal
Dolby D 64...67ms (nom.), depending on mode
Dolby D+ 64...67ms (nom.), depending on mode
Decoding Latency
PCM 20ms … 1 video frame, depending on mode
